Value Acoustics L1

Loudspeaker 3way Value Acoustics L1

Applications:

• Large-scale music festivals
• Outdoor plazas
• Stadiums
• Theatres and auditoriums

Technical Specifications：

• Frequency Response①: 68Hz–18kHz (±3dB), 60Hz–20kHz (-10dB)
• Nominal Coverage (-6dB): 90° (H) × 10° (V, adjustable)
• Sensitivity (1W/1m)②: 100dB
• Max SPL③: 129dB (AES) / 135dB (PEAK

Transducers:

• LF: 2 × 10″ neodymium paper-cone woofers
• MF: 1 × 8″ neodymium paper-cone driver
• HF: 1 × 3″ neodymium compression driver
• Dimensions (H×W×D): 304 × 810 × 506mm
• Net Weight: 36kg
• Connectors: 2 × NL-4 waterproof 4-pin sockets
• Cabinet Material: 18mm high-density multilayer birch plywood
• Finish: Black polyurea coating
• Grille: Black epoxy perforated steel with acoustic mesh
• Angle Adjustment: 0°, 1°, 2°, 3°, 4°, 5°, 6°, 7°, 8°, 9°, 10°

Notes:

①Frequency response curve measured in anechoic chamber (free field)

②Sensitivity measured in anechoic chamber (free field) at 1m on-axis with 1W

③Maximum SPL obtained under preset program conditions
